Jaylec Black Series Performance Alternator - Motorsport Application

The Black Series is an expanding range of high performance alternators designed for use on performance vehicles.

Made for vehicles that demand more than what O.E. manufacturer alternators can offer. Built to a high standard where reliability and performance are key, with the alternators designed specifically for vehicles that demand more than what the OE alternator offered – higher output (amperage) at lower cut-in speeds.

Intended to run high-demand components at idle, such as dual thermos-fans, injection systems, air conditioning, electric steering, monitoring systems, upgraded lighting systems and winches, while maintaining the battery at the desired levels.

With a rigorous design and testing phase, combined with efficient cooling fans and the highest quality bearings ensure that they can replace and outperform the most popular units in the market today.

All Black Series alternators have been amperage rated Hot and Cold.

Example:

• 13.5V @ 125A Cold - Cold is the alternator rectifier at 40ºc (maximum output)
• 13.5V @ 110A Hot - Hot is the alternator rectifier running at 96ºc for ½ hour (normal operating condition

Features:

• Designed for motorsport applications using +60 Amps at full load
• Alternator can be switched off & on while running
• Field wire allows alternator to be shut down during racing event.
• Shutting Alternator on and off may induce a voltage spike, this feature is used at the owoff.
• Fits Motorsport Applications
• Mount: Universal Motorsport

Specifications:
