SPAL Thermo Fan Pusher – 11.0" – 12V – 842 CFM – VA09-AP8/C-54S

High Output. Compact Cooling Solution.

The SPAL VA09-AP8/C-54S 11.0" (280mm) Pusher Fan delivers 842 CFM of airflow with a curved blade design, offering a powerful cooling upgrade for performance and custom applications. Ideal for auxiliary cooling systems, intercoolers, or tight engine bays where space and airflow are both critical.
Built for demanding environments, the IP68-rated 12V motor is fully sealed against water and dust. Its finger-guard shroud provides added safety without restricting airflow, making this fan a reliable option for street, off-road, and motorsport builds alike.

Technical Data Sheet

Specifications:

Feature Details
SPAL Model # VA09-AP8/C-54S
CoolDrive Code EF3531
Voltage 12V
Flow Direction Pusher
Blade Diameter 11" (280mm)
Blade Type Curved
Shroud Type Finger-Guard
Airflow (CFM) 842
Airflow (M³/H) 1431
Current Draw Up to 7.0 Amps
Ingress Rating IP68
Warranty 3-Year Manufacturer's Cover
SKU EF3531
Barcode # 9316042089899
Brand Spal
